Liquipoint FTW23 - Capacitance point level

Capacitance
Point level detection
Liquipoint FTW23

Cost effective point level switch for water-based liquids

FTW23
please wait
Loading price
Prices temporarily unavailable
Price on request
from CHF ??.-

Specs at a glance

  • Process temperature

    Standard:
    -20 ... 100°C
    Cleaning:
    -20 ... 135°C for 1h
    -4 ... 275F for 1h

  • Process pressure absolute / max. overpressure limit

    Vacuum ... 16 bar
    Vacuum ....232 psi

Field of application

The Liquipoint FTW23 is developed and built for the food industry and meets all international hygiene requirements. The device also fits perfectly for industrial applications in all industries. It is intended for use in applications in liquid media without build-up. The IO-Link capability allows easy parameter setting.

For use in storage tanks, mixing vessels and pipes. For water-based liquids; Ex works for media with dielectric constant > 20, with adjustment via IO-Link for media with dielectric constant > 1.5 discernible.

  • Process connections: Threads

  • Temperature: -20 to +100°C (-4 to +212°F), CIP/SIP to 135°C (275°F) for 1 hour

  • Pressure: -1 to 16bar abs (-14.5 to 232psi)

  • Hygienic certificates

Benefits

  • Easy installation thanks to compact design, even in tight conditions or where access is restricted

  • IO-Link reduces costs and complexity due to easy configuration of the devices via engineering tools

  • CIP and SIP cleanability ensured - up to protection class IP 69

  • Individual adjustment to each medium not necessary

  • LED display for on-site function check
